Murphy® bed frame and mechanism kits

For those who like a more hands-on approach with their Murphy beds. We supply the hardware, you take care of the cabinetry.

Lifetime
Warranty
Up to 2000 lbs
Weight Capacity
Quality European
Engineered Mechanism

Elite Aluminum

Bed frame and mechanism

SAVE 10% - USE CODE MWBH

Orientation

Bed Size

Options

Extended Legs

What is this?

$1,446.98 SAVE $400

^$1046^.98 CAD

Add to Cart

Two European manufactured counter-balanced spring loaded mechanisms
Aluminum bed frame
Crossbar
NEW 3 horizontal steel notched stiffeners
Two patented tubular legs
Cabinetry cut list
Assembly fasteners (ie. nuts, bolts, screws etc.)

Dimensions

44 1/2" w x 80 1/16" h x 15 7/8" d

Open: 84 1/2”

Mattress (not included)

39" x 75" x maximum 10" deep

A regular coil mattress is recommended

Supreme Steel

Bed frame and mechanism

SAVE 10% - USE CODE MWBH

Orientation

Bed Size

Options

Extended Legs

What is this?

$1,446.98 SAVE $400

^$1046^.98 CAD

Add to Cart

Two European manufactured counter-balanced spring loaded mechanisms
Steel bed frame
Crossbar
Two horizontal steel stiffeners
Two patented tubular legs
Cabinetry cut list
Assembly fasteners (ie. nuts, bolts, screws etc.)

Dimensions

44 1/2" w x 80 1/16" h x 15 7/8" d

Open: 84 1/2”

Mattress (not included)

39" x 75" x maximum 10" deep

A regular coil mattress is recommended

Extended Legs

The Extended Leg (14" leg height) option allows the use of a mattress up to 12" thick, but it will raise the height of the cabinet by 2 3/8". If the Extended Leg option is not chosen the hardware kit will come with the Regular Height Legs (12" leg height), which allows a mattress up to 10" thick

Super Springs

When the bed is in the upright position, the mechanism can support a maximum of 220 lbs, which includes the bed panel, bed frame, stiffeners, crossbar, legs and mattress. If the weight limit is exceeded a maximum of 2 Super Springs, per mechanisms, can be used to allow for approximately 20% more weight to be added to the front panel.

Which Murphy® Wall-Bed is right for you?

The quality of our wall-beds is clear.

9 clear points of quality

01

Reinforced corner brackets

These brackets connect the mitered corners of the side, end and head rails for added durability.

02

Counter-balanced spring mechanism

This European-engineered mechanism holds up to 9 steel springs and allows for safe and effortless opening and closing of the bed. When balanced correctly, it can hold the bed panel unit at a 45 degree angle.

03

Supportive steel stiffeners

Lightweight steel stiffeners (two for Supreme Steel, three for Elite Aluminum) reinforce and support the bed panel. They're strong enough to help support up to 1700 lbs, but so thin, they won't be felt through the mattress.

04

Side rails

Two sleek side rails connect to the end and head rails to surround and support the bed panel.

05

Leg stop

Installed into the bottom hole of the frame, the leg stop prevents the leg from fully rotating down.

06

Protective rubber feet

These long-lasting rubber feet protect your floor from damage.

07

Leg crossbar

Part of our patented rotational leg system, this square bar attaches to the two legs and rotates over the mattress when the bed is closed.

08

End and head rails

Two shorter end/head rails connect to the side rails to surround and support the bed panel.

09

Rotational leg system

Our own patented leg system allows the two legs, connected by the cross bar, to easily and conveniently rotate into the bed when closed. Available in two heights: Regular, which accommodates a mattress up to 10" thick, and Extended, which accommodates a mattress up to 12" thick (and also raises the height of the cabinet by 2 3/ 8").
